Metalclad Unswitched 13A Fused Conn Unit Neon

Sold out
Original price £4.45 - Original price £4.45
Original price
£4.45
£4.45 - £4.45
Current price £4.45
SKU CL053

Dimensions & Attirubtes

  • Dimensions (mm) 80 (W) x 80 (H) x 42 (D)
  • Plate Fixing Centres - Horizontal (mm) 60.3
  • Style Metal Clad
  • Finish Metal Clad Grey
  • Materials Front Plate & Mounting Box: Electrophoretically Coated Steel Insert, Fuse Drawer & Housing: Urea Neon Lens: Polycarbonate Terminals: Brass Terminal Screws: Steel & Yellow Passivated Internal Busbars: Formed Pressed Brass Earth Strap: Mild Steel
  • Rated Voltage (V~) (Ue) 250
  • Frequency (Hz) 50
  • Resistive Load Rating (A) 13
  • Fuse Fitted Rating & Type 13A (BS 1362)
  • Termination Type Screw
  • Terminal Size (mm) Ø5
  • Terminal Torque Value (Nm) 2
  • Terminal Capacity - Solid (mm²) 3 x 2.5 or 2 x 4
  • Switched No
  • Twin Earth Terminals Yes
