HC-3.6KW-HY

The Hanchu Single Phase Hybrid Inverter 3.68kW is a reliable, high-efficiency solar inverter designed for residential PV and battery storage systems. With 97.6% maximum efficiency, 150% PV oversizing, dual MPPT trackers and up to 5kW battery charge/discharge power, it helps maximise solar generation and improve home energy use.

Featuring EPS backup power, app-based remote monitoring, Octopus tariff integration, IP66 protection and a 12-year warranty, this compact hybrid inverter is a smart choice for modern solar and battery installations.

Downloads

Specifications

• Dimensions (W*H*D) (mm) : 483*455*193.5
• Device weight : 25.1Kg
• Operating temperature range : -25C ~+60C
• Noise emissions (typical) : 30 dB(A)
• Standby consumption : <10W
• Degree of protection (as per lEC 60529) : IP66

Features

• User interface : LED & APP
• Communication with BMS : RS485 / CAN
• Communication with meter : RS485
• Communication with portal : WiFi/Bluetooth
• Other communication : DRM
• Communication : /
• Integrated power control / Zero export control : Integrated/Integrated
• Certifications : EN 61000/IEC 62109/EN 50549/G98/G99/G100/VDE 4105/VFR 2019/NRS 097/CEI 0-21/NTS/IEC 61683/IEC 61727/IEC 62116
• Warranty : 12 years
